NuttX CI Process

NuttX is a complex system with lots of compile-time configurable switches and values. What’s more is that NuttX supports hundreds of different hardware targets, across multiple different architectures. This complexity makes it critical to have CI processes for testing incoming patches.

Note

The NuttX CI resources are limited, and not everything in the kernel can be reasonably tested in CI (for instance, there is currently no support for testing directly on hardware targets via CI, although it’s being worked on).

It is for this reason that NuttX still request patch authors perform their own local testing (especially on hardware where applicable) to submit alongside their patch so reviewers may have some confidence that the change will not introduce obvious regressions.

Tip

NuttX is always appreciative of improvements to our processes! If you have suggestions to improve the CI infrastructure, please let the community know. Our CI team is currently bearing a high workload.

The focus of this documentation is the CI testing that takes place when a PR is opened on the nuttx (and nuttx-apps) GitHub repositories.

CI Stages

When a PR is opened, the following CI actions take place:

Pull Request Labelling

This action is responsible for:

  • Labelling the PR with the label(s) corresponding to changed files (i.e. files changed under arch/arm/** are labelled Arch: arm).

  • Labelling the PR with a PR size (i.e. Size: XS, Size: M, etc.)

The workflow file for this action is located at .github/workflows/labeler.yml. This file contains documentation in the form of comments. To compute the PR labels, it:

  • Gets information about the changes from GitHub (i.e. files and lines changed)

  • Sums the total lines changed and assigns PR size labels based on this number

  • Uses the wildcard paths-to-label assignments in .github/labeler.yml to assign the correct change labels to PRs.

Types of labels are:

  • Arch labels (i.e. Arch: arm, Arch: risc-v, etc), associated with changes in arch/

  • Board labels (i.e. Board: arm, Board: sim, etc) associated with changes in boards/

  • Area labels (i.e. Area: Bluetooth, Area: Crypto, Area: Drivers) associated with several different kernel “areas”

Once this workflow is done running, the PRs labels are updated by the computed result and PRs in the pull-requests tab can be sorted according to these labels.

Tip

You can filter PRs by the Size: XS, Size: S to review small PRs quickly in between work :)

Checkpatch

More information about the checkpatch.sh tool itself can be found at checkpatch.sh.

The goal of this action is to verify that the PR adheres to the C coding standard, does not contain typos and adheres to the commit message format. Additionally, format checking of CMake files has been added to the checks.

The workflow file for this action is very short and can be found at .github/workflows/check.yml.

Build

This is the most complex step in the CI process, and also the longest duration. It selects a category of NuttX configurations (defconfig files) associated with the changed files and builds them all in parallel. It also uses the tools/refresh.sh utility to check if any configurations need to be normalized (see refresh.sh) for more information).

The workflow file for this check is located at .github/workflows/build.yml. The name of this workflow is deceiving, as it does not only build configurations, but also normalizes them and runs NTFC tests on architectures that support it.

The steps executed in the build workflow are:

  1. Fetch source: checks out nuttx and nuttx-apps repos. The source files are added as an artifact to the GitHub action so that it can be downloaded by subsequent steps.

  2. In parallel, the builds to be performed are selected for each host OS/setup supported by NuttX. These are Linux, MacOS, MSVC and MYSYS2.

    Note

    Typically only performed in the Linux environment. Performing the builds across all host options consumes too many resources.

    MacOS builds are currently always skipped, but sometimes tests are performed for MSVC and MYSYS2. These builds are a small subset of the total builds performed on Linux, but which were selected to still cover a range of architectures. Some selected builds are raspberrypi-pico:nsh, rv-virt:nsh, sim:windows, etc.

  3. Once the build is selected for a host configuration (i.e. Linux), the builds are performed in parallel. For example, if in Step 2 the selected Linux builds were arm-01, arm-02 and arm-03, this step will perform the build test for each category in parallel.

    This involves compiling all of the defconfig configurations included in each category and running tools/refresh.sh on them. Some categories, like sim-01 also perform NTFC tests. In this case, the NTFC runtime tests are run using the architecture’s designated citest/defconfig configuration.

  4. After each category’s builds are complete, make host_info is run in each category’s runner as a sanity check.

  5. After all the selected Linux builds complete, an out-of-tree (OOT) build test is performed. This is done using tools/ci/cibuild-oot.sh.

Each build category (arm-01, etc.) produces a build artifact which contains all of the resulting build outputs for that category. This includes the resulting nuttx.bin, nuttx.elf, nuttx.hex, etc., binaries. You should be able to download the artifact, flash the NuttX image(s) to your target device and test them that way if you’d like to avoid building all of the images yourself!
